- Product Name: SURI Electric Bed D
- Model Number: RMCJH381D1/ RMCJH381D2
- Dimensions: L2230xW1090xH490-790±10mm
- Material: Cold Rolled Steel, HDPE
Product Material
- Bed platform, structure and leg are all made of premium cold rolled steel with electrostatic powder coating.
- The Bed platform consist of four foldable sections, stamping frame (RMCJH381D1).
- The Bed platform is combined by PE plastic pillar, which is easy to clean and detachable (RMCJH381D2).
- Detachable HDPE bed headboard and footboard.
- Four-section HDPE side rails operated by gas spring.
- Four corner bumpers are for bed protective.
- The third side rails is made of premium quality cold rolled steel with electrostatic powder coating, which is rotated and lockable (Optional).
Product Parameters
- Bed Platform: 1980x900mm
- Backrest: 0-70°±5°
- Legrest: 0-40°±5
- Height adjustment: 490-790±10mm
- Trendelenburg and Revers Trendelenburg: 0-12°±3°
- Lateral Lilt: 0-30 °
- Brakes System: Central Brake
- Sticker Color: Wood Grain / Royal Blue
- Motors: 4 Motors
- Control Panel: Nurse Control / Remote Control
Product Feature
- Backrest 0-70°±5°, Leg rest 0-40°±5°, Height adjustment: 490-790±10mm, Trendelenburg and Revers Trendelenburg 0-12°±3°, Auto-contour, Calf Raising.
- Four motors, high quality and noise-free, with remote control.
- Manual CPR is to make the whole bed surface flatted.
- Electric CPR is to make the backrest board flatted quickly.
- Angle indicators are on the both side of backrest side rails.
- Weighing scale system, accuracy is 10g, (optional function)
- Clear acrylic head card for patient name display, Four infusion holes, four drainage hooks around the bed.
- Four 125mm diameter castors with central brake.
- The length of the bed can be extended 15cm (optional function).
- Auto regression reduce the abdominal pressure of patient.
Frequently Asked Questions
What are the dimensions and platform size of the SURI Electric Bed D?
The SURI Electric Bed D, model RMCJH381D, features an overall external dimension of L2230mm by W1090mm, with an adjustable height range between 490mm and 790mm. The internal bed platform, which supports the mattress, measures 1980mm in length and 900mm in width. For facilities requiring extra space for taller patients, the bed also offers an optional extension feature that can increase the total length by an additional 15cm.
What is the difference between the RMCJH381D1 and RMCJH381D2 SURI bed models?
The primary difference between these two models lies in the construction of the bed platform. The RMCJH381D1 model is designed with a four-section foldable stamping frame made of premium cold rolled steel. In contrast, the RMCJH381D2 model utilizes a bed platform combined with PE plastic pillars, which are specifically engineered to be easy to clean and fully detachable for high-standard hygiene maintenance.
What adjustable positions and motor functions does the SURI electric hospital bed offer?
This medical bed is powered by a high-quality, noise-free four-motor system that allows for a wide range of clinical positions. It supports backrest adjustment from 0 to 70 degrees, leg rest adjustment from 0 to 40 degrees, and height adjustment from 490mm to 790mm. Additionally, it features advanced therapeutic movements including Trendelenburg and Reverse Trendelenburg at 12 degrees, as well as a 0 to 30-degree lateral tilt capability to assist with patient turning and pulmonary care.
How do the emergency CPR and safety features work on the SURI RMCJH381D?
The SURI Electric Bed D is equipped with both manual and electric CPR functions to ensure patient safety during critical situations. The electric CPR function allows the backrest to be flattened quickly via the control panel, while the manual CPR lever enables the entire bed surface to be leveled instantly in the event of a power failure. Safety is further enhanced by four corner bumpers, a central braking system for the 125mm castors, and angle indicators built into the side rails for precise positioning.
What materials are used in the construction of the SURI Electric Bed D?
The SURI electric bed is built for durability and infection control using a combination of premium cold rolled steel and High-Density Polyethylene (HDPE). The main structure and legs are made of steel treated with an electrostatic powder coating to prevent corrosion. The bed’s headboard, footboard, and four-section side rails are manufactured from detachable HDPE, which is known for its impact resistance and ease of sterilization in a hospital environment.
