- Product Name: MEGA-MT (Three Functions Manual)
- Model Number: RMC-SO141A3/RMC-SO141B3
- Dimensions: L2257xW990xH470-680mm
- Function: Three Functions
- Material: Cold Rolled Steel, HPL, Aluminum Alloy
Product Material
- Bed platform, structure and leg are all made of premium cold rolled steel with electrostatic powder coating.
- The bed platform comprises four foldable sections, stamping frame.
- Detachable bed headboard and footboard, which are made of premium HPL, which is corrosion resistant, abrasion resistant, anti-fire and anti-statics, molding aluminum alloy frame with corner bumper.
- Two-section rotation side rails, made of premium cold rolled steel with electrostatic powder coating.
Product Parameters
- Bed Platform: 1980x900mm
- Backrest: 0-75°±5°
- Legrest: 0-45°±5
- Height Adjustment: 470 – 680±10mm
- Sticker Color: Beech / Chocolate / Walnut
- Brake System: Central Brake/Wheels Brake
Product Feature
- Backrest adjustment 0-75°±5°; Legrest adjustment 0-45°±5°; Height adjustment: 470-680±10mm.
- Clear acrylic head card for patient name display, Four infusion holes, four drainage hooks around the bed.
- Mechanical crank operation with overload protection.
- The screw handle is foldable under the bed footboard.
- Four 125mm diameter castors with central brake(RMC-SO141A3), four 125mm diameter castors with wheels brake(RMC-SO141B3).
Frequently Asked Questions
What are the primary functions of the MEGA-MT manual hospital bed?
The MEGA-MT manual hospital bed is designed with three essential functions to enhance patient comfort and clinical efficiency. These functions include a backrest adjustment that ranges from 0 to 75 degrees, a legrest adjustment from 0 to 45 degrees, and a comprehensive height adjustment capability that moves the bed platform between 470mm and 680mm. All these movements are operated via a mechanical crank system that features overload protection for added safety.
What materials are used in the construction of the MEGA-MT RMC-SO141A3 bed?
The construction of the MEGA-MT series utilizes high-quality industrial materials to ensure longevity and hygiene in medical environments. The bed platform, main structure, and legs are manufactured from premium cold-rolled steel coated with an electrostatic powder finish. For the headboard and footboard, the bed uses premium High-Pressure Laminate (HPL) within an aluminum alloy frame, ensuring the surfaces are anti-static, fire-resistant, and highly resistant to corrosion or abrasion.
What is the difference between the MEGA-MT RMC-SO141A3 and RMC-SO141B3 models?
The main distinction between the RMC-SO141A3 and RMC-SO141B3 models is the type of braking system installed on the mobility castors. While both models feature high-quality 125mm diameter wheels, the RMC-SO141A3 is equipped with a central braking system for simultaneous locking, whereas the RMC-SO141B3 utilizes individual wheel brakes. Both models maintain the same dimensions and three-function mechanical capabilities.
How does the height adjustment work on the MEGA-MT three-function manual bed?
The height adjustment on the MEGA-MT bed is managed through a manual screw handle located at the foot of the bed. This mechanical crank allows caregivers to raise or lower the bed platform from a minimum height of 470mm to a maximum height of 680mm to facilitate safer patient transfers and better ergonomic positioning for medical staff. To save space and prevent obstruction, the screw handle is designed to fold neatly under the bed footboard when it is not being used.
What patient safety and convenience features are included with the MEGA-MT medical bed?
The MEGA-MT manual bed includes several integrated features designed for patient management and safety, such as two-section rotation side rails made of powder-coated cold-rolled steel. For clinical convenience, the bed is outfitted with four infusion holes for IV poles, four drainage hooks located around the frame, and a clear acrylic head card specifically for displaying patient identification. The corners of the bed are also protected by bumpers integrated into the aluminum alloy headboard and footboard frames.
Product Introduction
Product Detail Display
