LCD Gas Spring Wall Mount (WM-9G)
LCD Gas Spring Wall Mount (WM-9G)
whatsApp Us
Description
This massive wall-mounted arm suspends a monitor weightlessly. The arm provides full articulation, allowing you to position the monitor anywhere within the arm's sphere of movement.
A vertical range allows this arm to be used while sitting or standing. The arm is a good choice for dental operatories, patient rooms, operating rooms... anywhere space is at a premium yet monitor placement flexibility is required
- Hidden cable management
- Gas spring inside supports height adjustment at any position
- Die cast aluminum structures
- Screen Size:15"-27"
- Load:0-8kg
- Tilt:'-90°~+85°
- Swivel:180°
- Rotation:360°
- Vesa:75/100
- Color: Black
- Material: Aluminum
| PRODUCT CATALOG | PRODUCT MANUAL |
|---|---|
 |
|
Frequently Asked Questions
Can this wall-mounted monitor arm be used for both sitting and standing positions?
This articulating arm features an extensive vertical range designed specifically to accommodate various working heights, making it an ideal solution for professionals who transition between sitting and standing throughout the day.[1] Because the internal gas spring allows for smooth and nearly weightless movement, you can effortlessly reposition your screen to maintain an ergonomic viewing angle whether you are at a desk or standing during a procedure.
What monitor sizes and weights are compatible with this gas spring wall mount?
This heavy-duty wall mount is engineered to support a wide variety of flat-panel displays ranging from 15 inches to 27 inches in size. To ensure the gas spring operates correctly for weightless positioning, the monitor must weigh between 0 and 8 kilograms while featuring standard VESA mounting patterns of either 75x75mm or 100x100mm.
Is this articulating monitor arm suitable for dental operatories and medical environments?
This wall-mounted arm is a premier choice for dental operatories, patient rooms, and operating rooms where floor and desk space is at a premium. Its die-cast aluminum structure provides the durability required for clinical settings, and its full sphere of movement allows healthcare providers to quickly share information with patients or move the screen out of the way when it is not in use.
How does the gas spring technology improve monitor positioning?
The integrated gas spring mechanism counterbalances the weight of your monitor to provide a weightless feel during adjustment. Unlike manual tightening mounts, this technology allows you to pull, push, or tilt the screen into any position with a light touch and have it stay exactly where you leave it without the need for tools or constant readjustment.
Does this monitor wall mount include a system for cable management?
The design of this arm includes a sophisticated hidden cable management system that routes all power and data wires through the internal structure of the die-cast aluminum arms. This feature ensures a clean and professional appearance in high-traffic areas like lobbies or medical offices while protecting cables from being snagged or unplugged during the arm's full 360-degree rotation.
