- Product Name: CONTOUR Sharing Be (Three Functions Manual)
- Model Number: RMCMY-SO171A1/ RMCMY-SO171B1
- Dimensions: L2250xW1425xH470-680mm
- Function: Three Functions
- Material: Cold Rolled Steel, HDPE, Clear Acrylic
- Bassinet：L750xW431xH300mm
Product Material
- Bed platform, structure and leg are all made of premium cold rolled steel with electrostatic powder coating.
- The bed platform comprises four foldable sections, stamping frame.
- Detachable bassinet is made of clear acrylic with mattress.
- Detachable ‘smile face’ HDPE bed headboard and footboard.
- Three-section ‘smile face’ HDPE gas spring side rails.
Product Parameters
- Bassinet: L750xW431xH300mm
- Bed Platform: 1980x900mm
- Backrest: 0-75°±5°
- Legrest: 0-45°±5
- Height Adjustment: 470-680±10mm
- Brakes System: Central Brake/ Wheels Brake
- Sticker Color: Wood Grain/ Royal Blue
- Side Rails: ABS Side Rails
Product Feature
- Backrest adjustment 0-75°±5°; Legrest adjustment 0-45°±5°; Height adjustment: 470-680±10mm.
- The detachable bassinet is specially design for taking care of newborn baby, with 360°visibility, with bassinet mattress.
- Mechanical crank operation with over control protection.
- The screw handle is foldable under the bed footboard.
- Clear acrylic head card for patient name display.
- Four infusion holes, four drainage hooks around the bed.
- Four 125mm diameter castors with central brake (RMCMY-SO171A1), four 125mm diameter castors with wheels brake (RMCMY-SO171B1).
Frequently Asked Questions
What are the primary features of the CONTOUR Sharing Bed with an integrated bassinet?
The CONTOUR Sharing Bed is a specialized three-function manual hospital bed designed specifically for maternity care, featuring a premium cold-rolled steel frame and a detachable clear acrylic bassinet. It offers 360-degree visibility for newborn monitoring and includes adjustable sections for the backrest and legrest to ensure maximum comfort for the mother while keeping the infant within safe reach. The bed is equipped with HDPE "smile face" headboards and side rails, providing a durable and aesthetically pleasing environment for postpartum recovery.
How do the manual adjustment functions work on the RMCMY-SO171A1 sharing bed?
This model utilizes a mechanical crank operation system equipped with over-control protection to adjust the bed platform according to the patient's needs. Caregivers can manually modify the backrest from 0 to 75 degrees, the legrest from 0 to 45 degrees, and the overall bed height between 470mm and 680mm. For added safety and convenience, the screw handles are designed to be foldable, allowing them to be tucked away under the bed footboard when not in use to prevent obstruction in the hospital room.
What is the difference between the RMCMY-SO171A1 and RMCMY-SO171B1 model numbers?
The primary technical difference between these two specific model numbers lies in their integrated braking systems for the 125mm diameter castors. The RMCMY-SO171A1 model is equipped with a central brake system that allows for synchronized locking of the wheels for better stability and ease of movement. In contrast, the RMCMY-SO171B1 model features individual wheel brakes on each castor, providing a different method for securing the bed in a fixed position based on the facility's preference.
Can the bassinet be removed from the CONTOUR Sharing Bed for independent care?
Yes, the bassinet is fully detachable and is specifically designed to facilitate easy newborn care and unobstructed visibility. It measures 750mm in length and 431mm in width, comes with its own dedicated mattress, and is constructed from clear acrylic to allow mothers to monitor their baby from any angle while lying in bed. This design promotes bonding and convenience by allowing the bassinet to be positioned or removed as needed during clinical procedures or room cleaning.
What materials are used in the construction of the CONTOUR Sharing Bed for durability?
The CONTOUR Sharing Bed is built for heavy-duty clinical use, utilizing premium cold-rolled steel with an electrostatic powder coating for the bed platform, structure, and legs to ensure long-term durability and resistance to corrosion. The headboard, footboard, and three-section gas spring side rails are made from high-density polyethylene (HDPE), which is known for being easy to clean and impact-resistant. Additionally, the bed includes clear acrylic components for the bassinet and a head card holder for patient identification, ensuring a blend of strength and functional clarity.
